(AUTOMATIC PIPE CUTTING & BEVELING MACHINE)
In this first Operator feeds the machine with tubes by crane or manual. Total load volume of loading & storage rack is 19 pieces of Ï159 tubes with 4 tonsâ load capacity. The storage rack is designed with a proper incline angle to enable the tube roll downward to kick-in position. The kick-in plates are driven by multiple-units of air cylinder, which can kick the tube onto feeding roller table one after another.
In this the pipe length fixing is done by AC servo system. So, feeding the tube with precise length All cut piece of pipe will be equally in length with help of parting & bevelling tool.
